DOUBLE BEAM SPECTROPHOTOMETER

PM-750 DOUBLE BEAM SPECTROPHOTOMETER

Durable, versatile, rugged, easy to operate, long life and
accurate in determining absorbency, % transmission and
concentration of liquid.
• Stable and accurate with capable of covering 190 to 1100 nm
• 8 position cuvette holder & USB computer interface
• High wavelength precision with great & compact shapes

Technical Specification
Wavelength range	190-1100 nm
Spectral bandwidth	1 nm
Working mode	T, A, C, E
Optical system	Double Beam
Scanning speed	Fast / medium / slow
Photometric range	0 to 200 %t, -0. 3-3. 0 abs, 0-9999c
Wavelength accuracy	+0. 3 nm
Wavelength reproducibility	0. 2 nm
Photometric accuracy	+ 0. 3 %t
Photometric reproducibility	0. 2 %t
Stray light	< 0. 5% t (nal. 220 nm, nano2 340 nm)
Baseline flatness	+ 0. 001 a
Stability	+0. 001 a (at 500 nm, after warming up)
Noise	+0. 001 a (at 500 nm, after warming up)
Detector	Dual silicon photodiode
Display	6 inches high light blue lcd
Powerac	220 v + 10%, 50 hz.
Dimensions	630 x 470 x 210 mm
Mass	26 kg

Accessories
Glass cells	4 nos.
Quartz cells	4 nos.
Fuse	3 nos.
Instrument cover	1 no.
Software cd	1 no.
USB cable	1 no.
Operation manual	1 no.
