MS-680 PVG ZENER DIODE CHARACTERISTICS APPARATUS (FORWARD & REVERSE V-I

To Study Forward & Reverse VI Characteristics of Zener Diode.
The instrument is housed in a Heavy duty metal box , comprises of
two moving coil volt meters mounted on the front panel for
measuring current and voltage. The connections for each meter is
brought out at 4mm sockets; one DC regulated continuously
variable power supply 0-15 Volts DC / 150 mA; Three Zener diodes
are mounted behind the front panel and the connections for Zener
diodes are brought out at 4mm sockets;One load resistance is
mounted behind the front panel and the connection are brought
out at 4mm sockets; one ON/OFF switch with jewel light is provided
on the front panel
Accessories Supplied:
Required number of Patch Chords andDetailed and illustrative
Instruction Manual
